| Characteristic | 1.1 | Model | CQD15 | CQD20 | CQD25 | CQD20-12M | |
| 1.2 | Power Type | Electric | Electric | Electric | Electric | ||
| 1.3 | Operation Mode | Seated Type | Seated Type | Seated Type | Seated Type | ||
| 1.4 | Load Capacity | Q(kg) | 1500 | 2000 | 2500 | 2000 | |
| 1.5 | Load Center | C(mm) | 500 | 500 | 500 | 500 | |
| 1.6 | Front Overhang | X(mm) | 183 | 183 | 183 | 183 | |
| 1.7 | Wheelbase | Y(mm) | 1470 | 1620 | 1620 | 1650 | |
| 1.8 | Reach Distance | L(mm) | 505 | 655 | 515 | 610 | |
| Weight | 2.1 | Service Weight（With Battery） | kg | 3340 | 3450 | 4200 | 5390 |
| Wheels, Chassis |
3.1 | Wheel Type | PU | PU | PU | PU | |
| 3.2 | Front Wheel | ∅×w(mm) | 267*114 | 267*114 | 267*114 | 267*114 | |
| 3.3 | Driving Wheel | ∅×w(mm) | 382*142 | 382*142 | 382*142 | 382*142 | |
| 3.4 | Front Wheelbase | b10(mm) | 1168 | 1168 | 1168 | 1322 | |
| Dimensions | 4.1 | Mast Height,Lowered | h1(mm) | 2105 | 2105 | 3550 | 4950 |
| 4.2 | Free Lift | h2(mm) | 1143 | 1143 | 2584 | 3985 | |
| 4.3 | Lifting Height | h3(mm) | 4500 | 4500 | 8000 | 12000 | |
| 4.4 | Height,mast entended | h4(mm) | 5497 | 5497 | 9496 | 12977 | |
| 4.5 | Height of Overhead Guards | h14(mm) | 2180 | 2180 | 2180 | 2180 | |
| 4.6 | Fork Clearance when Mast Lowered | h13(mm) | 35 | 40 | 45 | 40 | |
| 4.7 | Mast/Fork Title Angle | α/β（°） | 3/5 | 3/5 | 3/5 | 3/5 | |
| 4.8 | Overall Length（With Fork) | l2(mm) | 2477 | 2477 | 2477 | 2578 | |
| 4.9 | Overall Width | b1(mm) | 1270 | 1270 | 1270 | 1270/1460 | |
| 4.10 | Fork Size | s/e/l(mm) | 35/100/1070 | 40/122/1070 | 45/125/1070 | 40/122/1070 | |
| 4.11 | Fork Spread | b5(mm) | 210-705 | 244-705 | 250-705 | 260-840 | |
| 4.12 | Min. Ground Clearance | m2(mm) | 70 | 70 | 70 | 70 | |
| 4.13 | Aisle Width for Pallet 1000*1200 crossways | Ast(mm) | 2964 | 3007 | 3007 | 3010 | |
| 4.14 | Min. Turning Radius | Wa(mm) | 1800 | 1900 | 1900 | 1922 | |
| Performance | 5.1 | Max. Travel Speed (Unladen/Laden) | km/h | 14/14 | 14/14 | 10/8 | 14/14 |
| 5.2 | Lifting Speed (Unladen/Laden) | m/s | 0.330/0.245 | 0.450/0.340 | 0.340/0.220 | 0.450/0.340 | |
| 5.3 | Lowering Speed (Unladen/Laden) | m/s | 0.350/0.380 | 0.360/0.420 | 0.330/0.400 | 0.360/0.420 | |
| 5.4 | Max. gradeability (Unladen/Laden) | ％ | ≤10 | ≤10 | ≤10 | ≤10 | |
| 5.5 | Service Brake | Electromagnetic | Electromagnetic | Electromagnetic | Electromagnetic | ||
| Motor, Charger |
6.1 | Drive Motor | kw | 6.5AC | 6.5AC | 8AC | 6.5AC |
| 6.2 | Lift Motor | kw | 7.5AC | 15AC | 15AC | 15AC | |
| 6.3 | Battery Type | Lead Acid | Lead Acid | Lead Acid | Lead Acid | ||
| 6.4 | Battery voltage/nominal capacity | V/Ah | 48V300Ah | 48V400Ah | 48V400Ah | 48V400Ah | |
| 6.5 | Charger | V/A | 48V/40A | 48V/50A | 48V/50A | 48V/50A | |
| Other | 7.1 | Type of drive control | AC | AC | AC | AC | |
| 7.2 | Sound level at the driver's ear acc. to EN12053 | dB(A) | 75 | 75 | 75 | 75 |
