Description

Product Features
1. New design reinforced roof frame with superior anti roll ability.
2. Professional XCE electronic control proportional technology system, it has better performance than diesel forklift.
3. Full AC motor driving and lifting electric control system, it greatly reduces the difficulty of forklift maintenance.
4. It is equipped with the sixth generation cylinder buffer technology as standard to ensure high efficiency, energy saving and more reliable stability.
5. The whole vehicle equipped with two degrees of freedom steering front and back, left and right, more comfortable operation experience.
6. It has 24 degree cone seal greatly as standard to reduce the possibility of hydraulic system leakage.
7. The H-type three-stage deceleration integral axle can reduce the driving noise and enhances the kinetic energy conversion ratio.
8. Large capacity lithium iron phosphate battery (optional) can be fully charged within 2 hours, greatly improving the economy.
9. More than 3500 times of rechargeable lithium batteries (optional) ensure the forklift's continuous operation ability and service life time.
10. The high-performance charger can achieve 93% charging efficiency and reduce the cost continuously.

Product Specifications

Model		Unit	P35
Rated capacity	Q	kg	3500
Load center distance	C	mm	500
Power mode			Battery
Tyre type			Solid tyre
Max.lifting height	H	mm	3000
Free lifting height	H1	mm	145
Mast tilt angle front/rear	α/β	°	6/12
Length fork excluded	L'	mm	2555
Width	W	mm	1270
Mast height	H2	mm	2060
Overhead guard height	H3	mm	2200
Min.under clearance	H4	mm	135
Wheel base	L1	mm	1680
Min.Turning radius	R	mm	2270
Travelling speed loaded/unloaded		km/h	15.5/17
Lifting speed loaded/unloaded		mm/s	310/450
Gradeability loaded/unloaded		%	15/17
Motor	Drive motor power	kw	16.6
Motor	Pump motor power	kw	13.5
Battery	Voltage	V	80
Battery	Amphere	Ah	500/600/660
