Product Features
LPG and gasoline as fuel, more environmental.
Seat with safety belt and steady bar.
Low center of gravity, small turning radius, more stable and reliable.
Safe overhead guard.
Hydraulic gear-box and hydraulic steering
Dual air filter.
Streamline balance weight.
For LPG/Gasoline forklift, you can choose China engine, Nissan K25 engine andMitsubishi 4G64 engine.
Optional mast: 2-stage 3.3m/3.5m/4m mast; 3-stage 4.5m/5m/5.5m/6m/7.3m mast.
| Main Information |
| 1 |
Manufacturer |
HITOP |
| 2 |
Model |
Unit |
CPQYD40 |
| 3 |
Power type |
Gasoline/Liquefied gas/Natural gas |
| 4 |
Rated capacity |
kg |
4000 |
| 5 |
Operator type |
Drive in seat |
| Size |
| 6 |
Max. lift height of mast with Load-backrest |
mm |
4575 |
| 7 |
Max.lift height of fork(standard) |
mm |
3000 |
| 8 |
Height of mast (standard) |
mm |
2150 |
| 9 |
Free lift height(standard) |
mm |
150 |
| 10 |
Height of Load-backrest |
mm |
1240 |
| 11 |
Min. Turning radius(outside) |
|
mm |
2700 |
| 12 |
Min. Turning radius(inside) |
mm |
230 |
| 13 |
Min. Intersecting aisle |
mm |
2685 |
| 14 |
Mast tilt angle |
deg |
|
| 15 |
Fork size |
mm |
1070X130X50 |
| Performance |
| 16 |
Speeds |
Max.Drive speeds(with/without load) |
km/h |
18/19 |
| 17 |
Lifting speeds (with load) |
mm/s |
350/380 |
| 18 |
Lowering speeds(with /without full load) |
mm/s |
350/400 |
| Weight |
| 19 |
Total weight |
kg |
4270 |
