No | Item | Unit | Parameter |
1 | Rated Capacity | kg | 2000 |
2 | Lift height | mm | 4300 |
3 | Overall length | mm | 2780 |
4 | Mast closed height | mm | 2265 |
5 | Free lift | mm | 1365 |
6 | Ground clearance | mm | 50 |
7 | Overhead guard height | mm | 2270 |
8 | Chassis width rear | mm | 1240 |
9 | Chassis width front | mm | 980 |
10 | Load center | mm | 600 |
11 | Wheel base | mm | 1735 |
12 | Seat height | mm | 1220 |
13 | Mast tilt(back/fwd) | 。 | 3/1 |
14 | Mast rotate angle (left/right) | 。 | 220 |
15 | Ground speed | Km/h | 16 |
16 | Lift speed(load/unload) | m/s | 0.55/0.70 |
17 | Front tyre size | mm | 413*178 |
18 | Rear tyre size | mm | 457*178 |
19 | Lead acid battery | V/AH | 80/500 |
20 | Grade ability(load/unload) | % | 18/20 |
21 | Traction motor | AC | 19.5kw |
22 | Lifting motor | AC | 15kw |
23 | Transfer aisle width | mm | 2700 |
