| Items | Unit | CPCD120 | |
| Features | Rated Load | Q（t） | 12 |
| Load center | c（mm） | 600 | |
| Wheelbase | y（mm） | 3000 | |
| Weight | kg | 18000 | |
| Chassis | Tyre Specs.:Front | 10.00-20-16PR | |
| Tyre Specs.:Rear | 10.00-20-16PR | ||
| Tyres Qty,front/rear(X-drive wheels) | 4\2 | ||
| Wheel tread:Front | b10（mm） | 1650 | |
| Wheel tread:Rear | b11（mm） | 1970 | |
| Dimension | Mast/carriage tilt angle(front/rear) | Degree（°） | 6\12 |
| Mast height(fork lowered) | h1（mm） | 3100 | |
| Max.lifting height | h3（mm） | 3000 | |
| Mast height(fork raised) | h4（mm） | 4600 | |
| Height to head guard(height to cab) | h6（mm） | 3000 | |
| Overall length(with forks) | l1（mm） | 6055 | |
| Fork front vertical surface to the rear end of the vehicle | l2（mm） | 4855 | |
| Overall width | b1/b2（mm） | 2250 | |
| Fork dimension | s/e（mm） | 1200X180X90 | |
| Fork carriage width | b3（mm） | 2200 | |
| Mast min ground clearance(with load) | m1（mm） | 225 | |
| Wheelbase center min ground clearance(with load) | m2（mm） | 350 | |
| Min.Turning radius | Wa（mm） | 4450 | |
| Travel speed(with load/without load) | km/h | 23/26 | |
| Performance | Max.lifting speed(with load/without load) | mm/s | 220/270 |
| Max.Lowering speed(with load/without load) | mm/s | 450/300 | |
| Traction | kN | 90 | |
| Gradeablity(with load/without load) | ％ | 20/22 | |
| Driving brake | Hydraulic clamp disc | ||
| Engine | Engine brand/model | Optional one | Yuchai engine |
| YC6J150-T301 6.494L 110KW 2200rpm |
|||
| Optional two | Dongfeng Cummins | ||
| 6BT5.9-C130/QSB4.5-C130 4.5L 97KW 2200rpm |
|||
| Cylinder No. | 6\4 | ||
| Others | Transmission gears(Front/rear) | 2\2 | |
| Attachments working pressure | Mpa | 16 | |
| Attachments using oil amount | l/min | 40 | |
