4 Way Reach Truck | Multi Directional Forklift
Main Features：
CDD30 reach truck is a multi directional forklift that eliminates the need for right-angle turns, reducing the aisle width needed for long load handling and bulky loads. This narrow aisle forklift features a unique four-directional travel mode that enables outstanding maneuverability and efficiency, and results in less damage.
Product specifications：
| Brand |
Unit |
HITOP |
| Model |
|
CDD30 |
| Power Type |
|
Battery |
| Operation Type |
|
Seated |
| Service weight(incl. battery) |
kg |
5480 |
| Rated Capacity |
Q(kg) |
3000 |
| Load Center |
C(mm) |
600 |
| Lifting height |
h3(mm) |
3000 |
| Forks size |
l/e/s(mm) |
1200/150/50 |
| Front Overhang |
x(mm) |
305 |
| Mast ground clearance |
ml(mm) |
150 |
| Max. climbing ability |
%(tanθ ) |
8/10 |
| Driving speed(load/unload) |
km/h |
7.8/9 |
| Lifting speed(load/unload) |
mm/s |
230/350 |
| Lowering speed(load/unload) |
mm/s |
170/150 |
Product Features：
Long Load Handling
Whether you are handling bar stock, tubing, lumber or other long and bulky loads, the CDD30 Reach-Fork truck can increase your storage space by up to 40%. With a wide range of trucks built for specific long load handling applications and innovations, HITOP makes it easy to maximize your space.
Palletless Handling
Whether you are moving carpeting, steel, or other palletless loads, HITOP has the answer. The 4-Directional Reach truck is one of several options HITOP offers to maximize space utilization, decrease damage to inventory and increase productivity with palletless handling.
Simpler maintenance
1. Equipped with a large-screen LCD display instrument, which can intuitively display the vehicle running status, with fault display and disoperation alarm functions;
2. Remove the rear cover of the counterweight, and you can directly inspect the electrical control
About HITOP：
Hitop Machinery Co., Ltd. is a professional forklift manufacturer and supplier, with production base covering more than 30,000 square meters. We are an ISO9001/SGS certified enterprise. Our company has more than 15 years of experience of professional R&D technical team. We are specialized in electric forklift (battery forklift), diesel forklift, manual/electric pallet truck, manual/electric stacker, order pickers, lift table trucks, with capacity from 500kgs to 15000kgs. Our products are CE certified. Meanwhile, we have professional technical team in designing and producing which can meet different requirements from customers, to support OEM/ODM service, we offer 24 hours pre-sales and after-sales support, to ensure in-time communication between clients and us. Due to product serialization and standardization, all HITOP products are widely used in medicine, food, chemical, household electrical appliances, wool cotton textile, tobacco, electronics, machinery, furniture and many other industries.
Electric Forklift Supplier：HITOP
